1 5

Moza Racing

MOZA R9 V3 Wheel Base (9Nm)

MOZA R9 V3 Wheel Base (9Nm)

R 10,400.00
R 10,400.00
Sale Sold out
Shipping calculated at checkout.

R9 V3 Direct Drive Wheel Base

Key Features:
  • 9Nm DD Power
  • 21-bit Magnetic Encoder
  • High-Performance Servo Motor
  • NexGen 4.0 Force Feedback Algorithm
  • Intelligent Temperature Control System
  • Aviation-grade Aluminum
  • Industrial Conductive Slip Ring
  • Cloud-based Mobile App Control

9 N·m of Torque from a Direct Drive Servo Motor

The R9's 9N·m of torque can simulate a full range of steering forces and car handling characteristics.

21-Bit Magnetic Encoder

With 280MHz High-Performance Processor

Divides each full rotation into 2,097,152 precise steps
Delivers microscopic 0.00017° resolution
Enables ultra-smooth control feel and instant response
Reproduces exceptionally detailed force feedback

MOZA High-Performance Servo Motor

High Torque Density

Optimized slot-fill copper windings
High-permeability silicon steel core
NdFeB permanent magnets for maximum output

18-Slot/16-Pole Configuration

Multi-slot/pole design minimizes torque ripple
Enhanced damping for smoother feedback
Delivers precise and detailed steering response

Wide Torque Range

Low back-EMF design
Maintains consistent torque at high RPM
Eliminates abrupt torque drop-off

NexGen 4.0 Force Feedback Algorithm

Enhanced Dynamic Feedback
More refined and detailed force feedback
Sharper, more defined curbs and rumble strip sensations
Instant response to weight shifts and tire slip
New cogging torque compensation for ultra-smooth steering

iRacing 360Hz Mode

Delivers richer and more responsive force feedback
Heightens immersion and driving precision
Available via MOZA Pit House after the May iRacing update

FFB Interpolation Algorithm

Smooths out abrupt torque spikes and dips
Ensures a more natural, progressive force curve under all conditions

Game FFB Decoupling

Breaks down FFB signals into individually tunable elements
Dial in your setup exactly how you like it—your wheel, your rules

Force Feedback Equalizer

Adaptive vibration tuning based on driving scenarios
Delivers only the essential feedback while minimizing unnecessary vibrations
Strikes the perfect balance between realism and clarity for a truly immersive experience

Custom Force Feedback Curve Tuning

Fully adjustable, non-linear output for precise handling
Amplifies useful force cues while reducing distractions
Helps drivers sense traction loss sooner, enhancing control and confidence


Smart Temperature Control System

Our advanced system continuously monitors the temperature of the motor and electronic components and employs intelligent temperature control strategies to deliver stable and reliable performance in all circumstances.

Aviation Grade Aluminum Alloy Housing

Unmatched quality and durability. The MOZA R9's whole housing is made of aviation grade aluminum alloy.

Industrial Conductive Slip Ring

The base and the steering wheel are connected through a automotive-grade conductive slip ring with a life span of over 5 million revolutions.
The unique patented design has extremely high stability and durability while achieving infinite high-speed rotation.

APP Cloud Control

The settings of the wheel base, steering wheel, pedals, etc. can be modified through the MOZA APP. Settings can be imported with one click onto new simulators.

The Ultimate Control Hub for MOZA Ecosystem

MOZA Pit House

Unified Ecosystem Tuning
From wheelbase to pedals and everything in between, Pit House offers a unified interface for configuring your entire rig. With just one click, you can launch your favorite game with optimized device presets, saving time and eliminating setup hassles.
Effortless for Beginners, Powerful for Pros
New to sim racing? MOZA Pit House makes it easy with preloaded, game-specific profiles for popular titles. You’ll also find official MOZA-recommended setups and pro driver configurations, allowing you to get race-ready instantly—no technical knowledge required. For experienced drivers, the software provides deep customization capabilities to push performance boundaries.
Deep Force Feedback Customization
Pit House offers a robust 19-point force feedback tuning system. You can adjust parameters such as mechanical friction, road sensitivity, and dynamic damping to match your preferred driving feel. These advanced controls allow for intuitive experimentation, helping you learn how different settings affect car behavior on track.
Smart Road Feel Equalizer
With the Smart Road Feel Equalizer, the software intelligently filters out distracting high-frequency vibrations while preserving critical traction cues. This makes it easier to sense understeer, oversteer, and surface changes.
Dynamic FFB Curves
Paired with Dynamic FFB Curve Adjustment, you can shape the force response to be linear or nonlinear, amplifying key feedback zones and expanding the catchable slip angle for enhanced control during limit driving.
Advanced Wheel Configuration
Pit House gives you full control over wheel inputs, including dual-clutch paddles, rotary encoders, analog joysticks, and RPM LED lights.
Advanced Pedal Configuration
On the pedal side, you can calibrate travel range, pressure curves, and activation points, tailoring each pedal to your driving style. A built-in brake tuning assistant helps you optimize braking performance to improve lap consistency and reduce stopping distances.
Seamless Firmware Management
Keeping your system up to date is effortless. Pit House provides one-click firmware updates across all MOZA devices, regularly delivering performance improvements, updated force feedback algorithms, and compatibility upgrades for the latest racing titles.

Game Compatibility List

Assetto Corsa
Assetto Corsa Competizione
Forza Horizon 4 (Microsoft Store)
Forza Horizon 5
Euro Truck Simulator 2
American Truck Simulator
RaceRoom Racing Excperience
F1 2018
F1 2019
F1 2020
F1 2021
F1 22
F1 23
rFactor 2
Project CARS 1
Project CARS 2
Project CARS 3
WRC G
WRC 9
WRC 10
Dirt Rally
Dirt Rally 2.0
Dirt 4
iRacing
Wreckfest
KartKarft
Richard Burns Rally
Live For Speed
BeamNG.Drive
MudRunner
CarX Drift Racing Online
Automobilista 2

Compact Design

The integrated motor design results in a compact size that still retains a standard 4 hole bottom mount pattern. It can be easily installed onto the vast majority of dedicated rigs and floorstands. In smaller spaces the base can be assembled with a desktop clamp, saving space whilst providing a convenient and enjoyable driving experience anytime, anywhere.

What's Inbox

Specs

  • Platform: PC
  • FFB Drive System: Direct Drive
  • MOZA Pit House Control: Support
  • Max Wheel Rotation: 90~2700°
  • Housing Material: Aviation Grade Aluminum Alloy
  • Color: Black
  • Peak Torque: 9 Nm
  • Peak Power: 180W
  • Input Voltage: 110V~220V AC —> 36V DC
  • USB Refresh Rate: 1000Hz
  • Encoder Resolution: 21-bits
  • Indicator: YES
  • App Functions: Supported
  • Quick Release: Supported
  • Connection Ports: Power, DC Input, E-stop, USB, Dash, Shifter, Handbrake
  • Box Contents: R9 Wheel Base, User manual, Warranty card, Power supply, USB cable, Toolkit
  • Mounting Method: Bottom mount
  • Side Mount Option: With optional side mount bracket
  • Desk Clamp: Optional
  • Emergency Stop Switch: Optional
  • Online Firmware Upgrade: Applicable
  • Firmware Update: Applicable
